SERIES: FROM BOX PATTERN: 01 an inspired version from woo jae sung, ws92@cornell.edu, www.woojsung.com It is a nice flowy structure, of course not a box. Really? This is the simplest concept sketch of the form. Finding the mid points followed by creating interpolate curves and then loft surface. The details of development is given below: (1) Draw three control point curves - Direction along Y-axis (2) Copy three curves in Z direction (3) Prepare Bottom and Top curves - 1,2 & 3 to Bottom Curve - 4,5,& 6 to Top Curve (4) Loft Surface - using default options (5) Select the opposite edge curves - select the edges - select one of the opposite curves - orient the curves in same direction (6) Create Geodesic Curves - Divide the curves - Create Geodesic Curves using loft surface (7) Divide the Geodesic Curves (8) Moving the points in x direction
